1106990 Electric Window Regulator Mechanical Precision
1106990 Electric Window Regulator Technical Specifications
The 1106990 Electric Window Regulator (1106990, 1106989) utilizes hardened steel guide rails with 3-stage zinc plating for SCANIA 3 Series right-side window applications. Dual-bearing cable pulleys maintain ±1.2mm positional accuracy through 20,000 operational cycles. 2.8mm reinforced mounting brackets withstand door frame torsion up to 15Nm. Interchangeable with left-side models (1106989) using mirrored component orientation. Precision-stamped carrier plates feature anti-rattle clips for vibration dampening below 4Hz resonance frequencies. Pre-assembled nylon cable guides eliminate alignment adjustments during installation. Compatible with SCANIA's TR88X motor series through standardized 14-pin connectors. All fasteners include Loctite® pre-applied thread locker for permanent mounting. Direct replacement for EU-specification trucks manufactured between 1987-2023. Weather-resistant coating meets IP54 ingress protection standards.
Dual-OE Compatibility Profile
Vehicle Applications
- ▶ 3 Series Right-Hand Drive
- ▶ Cab-Over-Engine Models
- ▶ Long-Haul Configurations
- ▶ Municipal Service Trucks
System Integration
- ▶ TR88X Motor Assemblies
- ▶ SC33R Control Units
- ▶ GL45RH Wiring Harnesses
- ▶ FT21R Mounting Kits
Designed for SCANIA commercial vehicles requiring right-side window mechanism replacements with dual-OE compliance.
Construction Features
- ▶ Triple-Layer Coating
- ▶ Anti-Vibration Design
- ▶ Mirror-Image Engineering
Performance Metrics
- ▶ Cycle Durability
- ▶ Positional Accuracy
- ▶ Environmental Resistance
Compatible with OE: 1106990, 1106989 for SCANIA 3 Series trucks (EU specification 1987-2023) using TR88X/SC33R/GL45RH window systems
