1307897 Window Switch Multi-Generation Truck Integration EU 1963-2021
Universal Window Control Mechanism
The 1307897 Window Switch (1307897) serves as the primary window control interface for six decades of European commercial vehicles. Featuring military-grade thermoplastic housing with UV-resistant coating, this component maintains operational integrity across -30°C to +85°C environments. The dual-stage rocker mechanism allows simultaneous window positioning and child lock activation. Copper-alloy contacts rated for 20A continuous load incorporate anti-arcing technology, compatible with both 12V and 24V electrical systems. Modular design accommodates 8-pin (pre-2000) and 10-pin (post-2001) connector types found in CF65 (2001-2021) and F Series (1963-1999) trucks. Impact-resistant polycarbonate membrane withstands 500,000+ actuations while maintaining <3Ω contact resistance. Sealed compartments meet IP67 standards through triple-layer gasket protection. The ergonomic profile matches original door panel contours across 45/65/75/85 series models.
Cross-Compatibility Architecture
Historical Coverage
- ▶ F Series (1963-1999)
- ▶ 45/65 Series (1991-2000)
- ▶ 75/85 Series (1992-2005)
- ▶ CF65/85 (2001-2021)
- ▶ 95 Series (1987-2003)
Electrical Adaptation
- ▶ Mechanical Relay Systems
- ▶ Early CAN Networks
- ▶ Direct Motor Control
Designed per ECE R10 electromagnetic compliance and ISO 8820 circuit protection standards.
Operational Specifications
- ▶ 6mm Actuation Travel
- ▶ 20A Contact Rating
- ▶ 500k Cycle Lifetime
Construction Details
- ▶ Glass-Fiber Reinforced Housing
- ▶ Silver-Plated Terminals
- ▶ Triple-Sealed Chambers
Compatible with OE: 1307897 for CF65/85, F Series, 45/65/75/85/95 Truck Models 1963-2021
