TRUCK UNDERCARRIAGE SYSTEM 1658710 VOLVO Mudguard Bracket
Designed for Volvo FH/FL/FM series (1982-2005), the 1658710 Mudguard Bracket employs glass-fiber reinforced polyamide compliant with Volvo STD 4411-7 specifications. Features injection-molded construction with 4.2mm nominal wall thickness, achieving ±0.8% dimensional accuracy across -40°C to 90°C operational spectrum. Impact-modified polymer blend exceeds SAE J575 vibration endurance requirements.
Integrated mounting bosses ensure direct bolt-on compatibility with Volvo chassis configurations. Mold-flow optimized ribs provide structural reinforcement while maintaining weight reduction objectives per Volvo Lightweight Design Directive 8.3.
MATERIAL ENGINEERING
- ▶ Material grade: PA6-GF30
- ▶ Thermal range: -40°C-90°C
- ▶ Tensile strength: 85MPa
- ▶ Fastener size: M10
- ▶ Weight capacity: 18kg
- ▶ Wall thickness: 4.0-4.5mm
VEHICLE INTEGRATION PROFILE
Direct replacement for OE 1658710/1608598 across Volvo 1982-2005 models. Compatible with FH12/FL10/FL12/FM series. Installation parameters meet Volvo Body Builder Guidelines 7.4. Material compliance aligns with ECE R55-02 regulations for commercial vehicle underbody components.
