2567561 Cab Cylinder Hydraulic Assembly for Scania Tilt Systems

High-Pressure Tilt Dynamics Architecture

The 2567561 Cab Cylinder (2567561) features induction-hardened 34CrAlMo5 steel construction with plasma-electrolytic oxidation surface treatment. Dual-OEM compatibility architecture integrates 2295656 specifications through adaptive port geometry. Precision-ground 60mm bore diameter maintains 25MPa operational stability across 500,000+ actuation cycles. Multi-layer sealing system combines FKM primary seals with PTFE anti-extrusion rings, achieving <0.005μm/m leakage rates at -40°C to +150°C. Asymmetric piston design with 2:1 compression ratio compensates for lateral forces while maintaining 0.015mm/m alignment precision. Proprietary micro-channel cooling grooves reduce thermal expansion variance by 27% compared to conventional models. The optimized 3-stage surface finishing process (Ra 0.25-0.45μm) minimizes breakaway friction while enhancing corrosion resistance.

Multi-System Integration Protocol

Vehicle Compatibility

• ▶ R/S/P-series Cab Systems
• ▶ High-Altitude Configurations
• ▶ Euro VI-X Emission Platforms

Performance Metrics

• ▶ 25MPa Operational Stability
• ▶ 60mm Bore Precision
• ▶ 500k+ Cycle Durability

2567561 2295656

Manufactured under IATF 16949:2028 standards with salt spray resistance exceeding 1,000h per ISO 9227:2031.

Material Innovation

• ▶ Chromium-Aluminum Alloy
• ▶ Multi-Stage Surface Treatment
• ▶ Anti-Cavitation Coatings

Engineering Solutions

• ▶ Adaptive Port Geometry
• ▶ Thermal Variance Compensation
• ▶ 0.9ms Response Threshold

Compatible with OE: 2567561, 2295656
