82144986 Volvo Bracket Step for Cab Access
Optimized for heavy-duty truck maintenance, the 82144986 Volvo Bracket Step (82144986) features laser-cut 4mm steel construction with anti-corrosion zinc-nickel coating. Designed specifically for VOLVO FH and FM series (2012-2021 EU-class trucks), this structural component provides 280mm×180mm stepped surface area with diamond-tread pattern. The pre-drilled M10 mounting holes align with factory chassis brackets across FH4 platform variants, offering direct bolt-on replacement capabilities without welding modifications.
Engineering Specifications
Fabricated from DC04 cold-rolled steel, each bracket undergoes triple-stage surface treatment: electrochemical cleaning, zinc-nickel alloy deposition (12μm thickness), and epoxy powder coating (RAL 7021). The OEM-Matched Geometry ensures ±0.3mm dimensional accuracy for seamless integration with VOLVO FM cabs manufactured between Q3 2012 and Q4 2021. Reinforced gussets at stress concentration zones increase load capacity to 600kg dynamic/1200kg static.
Vehicle Compatibility
- ▶ FH Series (2012-2021)
- ▶ FM Euro VI Models
- ▶ Globetrotter XL Cabs
- ▶ 4x2/6x4 Chassis
Design Features
- ▶ 15° angled entry surface
- ▶ 6mm rolled front edge
- ▶ 4-stage corrosion protection
