9737201746 Window Lifter Electric Drive Assembly
9737201746 Dual-Channel Lift Mechanism
This 9737201746 Window Lifter system replaces OEM components 9737201746, A9737201746, A9737200346, 9737200346, 9737200446, A9737201846, A9737200446, and 9737201846. Features 24V brushless motors with 18.5:1 planetary gear reduction for silent operation. Bilateral aluminum tracks maintain 0.1mm/m alignment accuracy under full 45kg load. Cross-compatible 12-pin connectors integrate with existing vehicle CAN networks. Thermally conductive polymer housing dissipates heat within 13.8-14.4V operating range. Pre-calibrated Hall sensors provide position feedback compatible with MB Star Diagnostic systems. Self-lubricating nylon rollers ensure smooth travel across 500mm window height.
9737201746 Multi-Platform Compatibility
Left-Side Applications
- ▶ Actros MP1-MP3 Cab
- ▶ Axor 1840-3340
- ▶ Atego 2nd Gen
Right-Side Applications
- ▶ Arocs 3245-4165
- ▶ Zetros 2733-4045
- ▶ Unimog U423/U530
Maintains original 72±2 N·m torque specifications for electric lift systems.
Technical Specifications
- ▶ 18.5:1 Planetary Gearbox
- ▶ IP67 Sealed Housing
- ▶ Glass-Filled Nylon Carriers
Certifications
- ▶ ISO 16750-3
- ▶ ECE R10.06 EMC
- ▶ DIN 75220 Endurance
Compatible with MERCEDES-BENZ Actros/Axor/Atego/Arocs/Zetros/Unimog (1970-2021) requiring OE: 9737201746, A9737201746, A9737200346, 9737200346, 9737200446, A9737201846, A9737200446, 9737201846
