1366849 Window Regulator | ISO 15037-2 EU-Class Truck Assembly
1366849 Window Regulator | ISO 15037-2 EU-Class Truck Assembly
Couldn't load pickup availability
1366849 Window Regulator Mechanism Structural Integration System
1366849 Window Regulator Technical Specifications
The 1366849 Window Regulator (1366849) employs stamped 3.0mm steel guides with zinc-alloy rollers for durable operation in SCANIA 3-Series trucks (1994-2008). Dual-channel rail construction maintains precise window alignment across 142294 and 2162366 configurations. Phosphate coating on components provides corrosion resistance in extreme temperatures (-30°C to +110°C). Snap-fit bushings enable maintenance without specialized tools, while interlocking drum teeth prevent cable slippage through 80,000+ cycles. Forged pivot points eliminate wear in manual systems, compatible with 2303349 and 2572349 brackets. Symmetrical mounting design allows mirror-image installation in EU-spec cabs. Alignment indicators ensure proper track positioning during replacement of 1366850 equivalent regulators.
1366849 Multi-Application Compatibility Matrix
Vehicle Applications
- ▶ 3-Series Day Cabs
- ▶ EU-Spec Models
- ▶ 1994-2008 Production
Interchange Codes
- ▶ 1366849/142294
- ▶ 2162366/2303349
- ▶ 2572349/1366850
- ▶ 1442295/2162367
- ▶ 2303352/2572351
Maintains original equipment specifications for vertical window travel and seal alignment across all supported configurations.
Mechanical Advantages
- ▶ Dual-Channel Rail System
- ▶ Heat-Treated Pivot Joints
- ▶ Anti-Corrosion Surface
Installation Design
- ▶ Snap-Fit Bushing Design
- ▶ Pre-Assembled Modules
- ▶ Visual Alignment Guides
Compatible with OE: 1366849, 142294, 2162366, 2303349, 2572349, 1366850, 1442295, 2162367, 2303352, 2572351 for SCANIA 3-Series Trucks (1994-2008 model years)
1366849 Window Regulator | ISO 15037-2 EU-Class Truck Assembly
