HEAVY DUTY CABIN STRUCTURE 20731717 VOLVO FM FH
The 20731717 VOLVO FM FH structural bracket employs high-grade aluminum alloy with T6 heat treatment. Engineered for FM/FH series trucks in 2002-2021 configurations, this component features robotic welding compatibility and ISO 14798:2015 compliance.
Features 1.82kg optimized mass for dynamic load distribution. The CNC-machined surfaces ensure structural alignment precision across FH12/FH16 variants, compatible with ROPS/FOPS safety systems and modular cabin designs.
ENGINEERING PARAMETERS
- ▶ Material grade: 6061-T6
- ▶ Surface hardness: 95 HRB
- ▶ Tensile strength: 310MPa
- ▶ Thickness: 5.0±0.2mm
- ▶ Drill tolerance: ±0.25mm
- ▶ Temp range: -50°C/+150°C
VEHICLE INTEGRATION
Validated for FH12 6×4/FH16 8×4 variants. Compliant with ECE R29 safety standards for commercial vehicle cabins. Certified in 1993-2021 production batches including heavy haulers, refrigerated trucks, and construction vehicles.
