22154286 Control Panel Operator Interface
Multi-Function Driver Console
The 22154286 Control Panel assembly (22154286, 21489840, 14050087) features laser-etched membrane switches with tactile feedback for cab environment operation. Dual-layer PCB design isolates high-current circuits from logic components. Anti-glare polycarbonate surface maintains visibility under direct sunlight. Integrated CANbus decoder translates switch inputs to J1939 protocol for FMX series trucks. Die-cast zinc alloy frame resists vibration in NH12/NH16 applications. Sealed rotary encoder prevents dust ingress in construction vehicles. Backlit symbols (20cd/m² luminance) ensure nighttime visibility without glare. Tool-free mounting clips enable 15-minute replacement in FH750 models. Dual-stage latching mechanism provides positive engagement for critical functions. Overcurrent protection (15A max) safeguards electrical systems. Compatible with Volvo's VECU 2.0+ architecture through ISO 11783-compliant interfaces.
Volvo Truck Compatibility Matrix
Core Applications
- ▶ FH Series (2011-2025)
- ▶ FM 9/10/12 (2005-2021)
- ▶ FMX 16 (2016-2024)
- ▶ NH9/NH12 (2008-2018)
Extended Fitments
- ▶ FH16 750HP
- ▶ Euro V-VI Models
- ▶ VECU 2.0+ Systems
Direct replacement for driver-side control modules with E-mark certification (R10).
Technical Specifications
- ▶ IP67 Environmental Seal
- ▶ -30°C to 85°C Range
- ▶ 24V DC Operation
Construction
- ▶ Zinc Alloy Subframe
- ▶ 0.8mm Steel Backplate
- ▶ 6-Pin Waterproof Connector
Compatible with OE: 22154286, 21489840, 14050087 for Volvo FH/FM/FMX/NH Series 2005-2025
