3176545 Window Regulator Electrical Operation System
3176545 Window Regulator Multi-Platform Compatibility
This 3176545 Window Regulator integrates 3176545, 1063291, 3981923, 1062008, 3176541, 3176546, 3981924, and 3176542 configurations for VOLVO's commercial vehicle series. Die-cast aluminum housing protects 12V DC motor from 200°F engine heat. 0.8mm stainless steel cables maintain tensile strength above 1,500N during -22°F winter operations. Pre-calibrated limit switches prevent window overtravel beyond 720mm stroke length. Left/right specific harness connectors match original 8-pin door wiring layouts. Vibration-dampened mounting brackets absorb 15G shock loads across rough terrain. IP67-rated seals block road dust ingress in desert environments. Thermal-managed polymer gears withstand 10,000+ cycles at 85dB noise levels.
3176545 Cross-Series Electrical Integration
Core Platforms
- ▶ FM12/FM10 (1998-2005)
- ▶ NH12/NH16
- ▶ FM7/FM9 Legacy
Special Configurations
- ▶ FMX Construction
- ▶ FH Sleeper Cab
- ▶ FM Low Entry
Maintains original 0.25s window response time with 35N·m torque output.
Electrical Components
- ▶ Copper Alloy Brushes
- ▶ PTFE-Insulated Wiring
- ▶ Chromium-Plated Contacts
Certifications
- ▶ ISO 16750 Vibration
- ▶ SAE J1455 Sealing
- ▶ RoHS 3 Compliant
Compatible with VOLVO FM/FH/FMX/NH Series (1998-2005) requiring OE: 3176545, 1063291, 3981923, 1062008, 3176541, 3176546, 3981924, 3176542
