9417200446 Window Regulator Manual Lift Assembly
9417200446 Dual-Sided Lift Mechanism
This 9417200446 Window Regulator replaces original equipment components RH 9417200446, LH 9417200346, and their derivatives. Features cold-forged steel cables with 1.8mm diameter in 3:1 pulley configuration. Zinc-nickel coated carrier plates prevent corrosion under 35kg vertical load. Universal mounting points accommodate Actros cab variations from 1996-2010 models. Glass-fiber reinforced nylon rollers operate within ±0.2mm tolerance across 480mm travel range. Pre-lubricated stainless steel guide channels ensure smooth operation between -25°C to +75°C. Bilateral tension springs maintain 45±5N counterbalance force for manual operation stability. Compatible with 5mm-6mm window glass thickness through adjustable clamping system.
9417200446 Cross-Generation Compatibility
Right-Hand Configurations
- ▶ Actros MP1-MP3 Doors
- ▶ 1996-2005 Classic Cabs
- ▶ Euro II/III Emissions Models
Left-Hand Configurations
- ▶ StreamSpace/Classic Space
- ▶ 2006-2010 Facelift Versions
- ▶ 4x2/6x4 Chassis Types
Maintains original 7.5:1 mechanical advantage ratio for manual operation systems.
Construction Features
- ▶ 304 Stainless Steel Rails
- ▶ PTFE-Impregnated Rollers
- ▶ Hot-Dip Galvanized Carriers
Performance Certifications
- ▶ ISO 9227 Salt Spray
- ▶ DIN 75230D Cycle Test
- ▶ ECE R43 Vibration
Compatible with MERCEDES-BENZ Actros (1996-2010) requiring OE: RH 9417200446, LH 9417200346, 9417200446, 9417200346
